Item Main Technical Parameters |
|||
|
Rated Load Capacity (kg) |
500 |
||
|
Rated Passenger Capacity |
4 |
||
|
Maximum Traction Force (kN) |
14 |
||
|
Minimum Ground Clearance(mm) |
180 |
||
|
Minimum Turning Radius (mm) |
Inside: 4100 / Outside: 6450 |
||
|
Gradeability(°) |
14 |
||
|
Maximum Speed (km/h) |
1st Gear |
4 |
|
|
|
2nd Gear |
9 |
|
|
|
3rd Gear |
15 |
|
|
|
4th Gear |
20 |
|
|
|
Reverse Gear |
9 |
|
|
Overall Dimensions in Transport Condition |
Length (mm) |
4540 |
|
|
|
Width(mm) |
1505 |
|
|
|
Height (mm) |
2080 |
|
|
Curb Weight (kg) |
2360 |
||
|
Wheelbase(mm) |
2710 |
||
|
Wheel Track (Front/Rear) (mm) |
Front1350/Rear1300 |
||
|
Starting Method |
Electric Start |
||
|
Transmission Type |
Mechanical Transmission |
||
|
Fuel Tank Capacity(L) |
36 |
||
|
Braking Type |
Service/Parking/Emergency Brake |
Four-wheel braking, spring-applied brake, hydraulic release, wet disc brakes |
|
|
Drive Type |
Rear-wheel drive |
||
|
Steering Type |
Hydraulic power steering |
||
|
Diesel Engine |
Model |
4L88 |
|
|
|
Rated Power (kw) |
65 |
|
|
|
Rated Speed(r/min) |
2600 |
|
