Item Main Technical Parameters |
||||
|
Model |
CPCDB50 |
|||
|
Rated Load Capacity (kg) |
5000 |
|||
|
Steering control type |
Hydraulic Steering Type |
|||
|
Curb weight |
8520 |
|||
|
Overall Dimensions L×W×H (mm) |
Overall Length (without Forks) |
3510 |
||
|
Overall Length (with Forks) |
4730 |
|||
|
Overall Width |
1995 |
|||
|
Mast Lowered Height |
2500 |
|||
|
Mast Lifted Height |
4365 |
|||
|
Overall Height (with FOPS/ROPS) |
2470 |
|||
|
Wheelbase (mm) |
2250 |
|||
|
Front Track /Rear Track(mm) |
1470/1700 |
|||
|
Minimum Ground Clearance(at Mast) (mm) |
195 |
|||
|
Maximum Traction Force (kN) |
42 |
|||
|
Gradeability (°) |
12 |
|||
|
Travel Speed per Gear (km/h) |
Forward |
1-gear |
5 |
|
|
2-gear |
20 |
|||
|
Back
|
1-gear |
5 |
||
|
2-gear |
20 |
|||
|
Minimum Turning Radius (mm) |
Inside (mm) |
300 |
||
|
Outside(mm) |
3300 |
|||
|
Braking Type |
Service Brake |
Front wheel hydraulic brake, wet brake
|
||
|
Parking Brake/Emergency Brake |
Central Brake, caliper disc brake |
|||
|
Maximum lifting height(mm) |
12 |
|||
|
Free Lifting Height(mm) |
3000 |
|||
|
Fork size |
195 |
|||
|
Fork adjustment range |
60×1220×150 |
|||
|
(outside of fork) (mm) |
300～1710 |
|||
|
Mast tilt angle (forward/backward) (°) |
6/12 |
|||
|
Front/rear overhang (mm) |
590/670 |
|||
|
Maximum lifting speed(mm/s) |
450 |
|||
|
Dropping speed(mm/s) |
300 |
|||
|
Flameproof Diesel Engine Model |
ZL4105DZLDFB |
|||
|
Flameproof Diesel Engine Power (kW) |
62 |
|||
|
Flameproof Diesel Engine Rated Speed (r/min) |
2200 |
|||
|
Protection Type |
Electric protection |
|||
