Item Main Technical Parameters | ||||||
Model | WC4SJ | |||||
Curb weight | 5350 | |||||
Rated Load Capacity (kg) | 5000 | |||||
Overall Dimensions L×W×H (mm) | 5000×1800×2300 | |||||
Tank volume (m³) | 4 | |||||
Wheelbase (mm) | 3300 | |||||
Front Track (mm) | 1700 | |||||
Rear Track (mm) | 1560 | |||||
Minimum Ground Clearance (Loaded, mm) | 180 | |||||
Gradeability (°) | 12 | |||||
Travel Speed per Gear (km/h) | 1st Gear | 5 | ||||
2nd Gear | 10 | |||||
3rd Gear | 15 | |||||
4th Gear | 20 | |||||
5th Gear | 27 | |||||
Reverse Gear | 7 | |||||
Minimum Turning Radius (mm) | Outside(mm) | 8500 | ||||
Inside (mm) | 5300 | |||||
Maximum Traction Force (kN) | 22 | |||||
Transmission Type | Mechanical Transmission | |||||
Braking Type | Service Brake/Parking Brake/Emergency Brake | Four-wheel braking, spring-applied brake, hydraulic release, wet disc brakes | ||||
Drive Type | Rear-wheel drive | |||||
Fuel Tank Capacity(L) | 75 | |||||
Flameproof Diesel Engine Model | ZL4105DZLDFB | |||||
Flameproof Diesel Engine Power (kW) | 62 | |||||
Flameproof Diesel Engine Rated Speed (r/min) | 2200 | |||||
Protection Type | Flameproof electric protection | |||||
Approach Angle (°) | 16 | |||||
Departure Angle (°) | 15 | |||||
Rear Overhang (mm) | 1420 | |||||
Axle Load | Unladen (kg) | Front Axle | 2480 | |||
Rear Axle | 2870 | |||||
Fully Laden (kg) | Front Axle | 3240 | ||||
Rear Axle | 6110 | |||||
Spray Width(m) | 8-10 | |||||
Water Flow Rate(L/s) | 3.7 | |||||
Monitor Range(m) | 18 | |||||
Suction Time(min) | 5 | |||||
Suction Depth(m) | 4 | |||||
Discharge Time(min) | 4 | |||||
Discharge Angle(°) | 45 | |||||
Vacuum Pump | Model | XD-40/40A | ||||
Speed(r/min) | 900 | |||||
Pumping Speed(m³/h) | 40 | |||||
Shaft Power(≤kW) | 8 | |||||
Vacuum Degree(MPa) | -0.09 | |||||
