Item Main Technical Parameters |
|||||
|
Model |
WC11R(A) |
||||
|
Curb weight |
2500 |
||||
|
Rated passenger capacity (person) |
11 |
||||
|
Overall Dimensions L×W×H (mm) |
5300×1830×2020 |
||||
|
Wheelbase (mm) |
3030 |
||||
|
Front Track (mm) |
1495 |
||||
|
Rear Track (mm) |
1430 |
||||
|
Minimum Ground Clearance (Loaded, mm) |
185 |
||||
|
Gradeability (°) |
14 |
||||
|
Travel Speed per Gear (km/h) |
1st Gear |
10 |
|||
|
2nd Gear |
16 |
||||
|
3rd Gear |
20 |
||||
|
Reverse Gear |
9 |
||||
|
Minimum Turning Radius (mm) |
Outside(mm) |
7150 |
|||
|
Inside (mm) |
4350 |
||||
|
Maximum Traction Force (kN) |
16 |
||||
|
Transmission Type |
Mechanical Transmission |
||||
|
Braking Type |
Parking Brake （Emergency /BrakeParking Brake） |
Four-wheel braking, spring-applied brake, hydraulic release, wet disc brakes |
|||
|
Drive Type |
4x4 drive |
||||
|
Fuel Tank Capacity(L) |
53 |
||||
|
Flameproof Diesel Engine Model |
ZL495DZLDFB |
||||
|
Flameproof Diesel Engine Power (kW) |
48 |
||||
|
Flameproof Diesel Engine Rated Speed (r/min) |
2600 |
||||
|
Protection Type |
Flameproof electric protection |
||||
|
Approach Angle (°) |
20 |
||||
|
Departure Angle (°) |
14 |
||||
|
Rear Overhang (mm) |
1360 |
||||
|
Axle Load |
Unladen (kg) |
Front Axle |
1150 |
||
|
Rear Axle |
1350 |
||||
|
Fully Laden (kg) |
Front Axle |
1279 |
|||
|
Rear Axle |
1991 |
||||
